In modern construction and industrial production, the demand for precision and efficiency in rebar processing is constantly increasing. The rebar straightening machine launched by YG is precisely designed to meet this demand. This equipment is specifically engineered for processing rebar with diameters ranging from 4-14mm. It boasts powerful versatility, not only capable of straightening and cutting ordinary rebar but also effortlessly handling various wire materials such as stainless steel wire, aluminum wire, cold-drawn wire, and even plastic-coated steel wire. Its outstanding performance ensures flat cuts and minimal errors, significantly improving processing quality.
Technical Parameters of Rebar Straightening And Cutting Machine
| Model | YGT 4-14 | YGT 5-16 |
| Diameter adjustment range | 4-14mm ( Ⅲ grade steel) | 5-16mm ( Ⅲ grade steel) |
| Wire pulling speed | 50m/min | 50m/min |
| Traction motor power | 2.2kw-6 | 2.2kw-6 |
| Modulation motor power | 7.5kw-4 | 15kw-4 |
| Cut off motor power | 5.5kw | 5.5kw-4 |
| Cutting error | ±0.5-1cm | ±0.5-1cm |
| Wire Length | 800-9000mm (can be lengthened) | 800-9000mm (can be lengthened) |
| straightening degree | ±2 mm/m | ±2 mm/m |
| Weight | 1500kg | 1500kg |
| Size | 2800*650*1200mm | 3300*650*1300mm |
Product Advantages of Rebar Straightening Machine
- Microcomputer Control, Easy Operation: The equipment adopts an advanced microcomputer control system, realizing automatic straightening, automatic length setting, and automatic cutting, greatly reducing operational difficulty. Users can simultaneously input multiple batches of lengths and quantities, which the computer intelligently stores, enhancing production efficiency.
- Hydraulic Cutting, Precise and Efficient: Utilizing hydraulic (dual-pipe dual-blade) cutting, it ensures no material jamming during the cutting process, resulting in more precise and quieter cuts, with a cutting error controllable within 5mm, far exceeding industry standards and effectively avoiding cutting errors. The cuts are flat, and no sparks are generated during processing, enhancing safety.
- Stable Performance, Convenient Maintenance: A pure copper motor provides strong power and excellent stability. The heavy-duty disc design, combined with easy-to-cut forged gears, ensures smooth operation and low failure rates. Moreover, the equipment is easy to maintain, and spare parts are economically priced, saving users on long-term operating costs.
- High Production Efficiency, Small Footprint: The wire drawing speed can reach 50 meters per minute, significantly boosting production efficiency. Its compact design results in a small footprint, facilitating easy movement and installation, adapting to various working environments.
- Intelligent Control, Remote Operation: Remote start and stop functionality is available within a 30-meter range, providing great convenience and safety for operators.
- Adjustable Speed, Meeting Diverse Needs: The equipment’s high speed can be adjusted according to your actual requirements, satisfying the demands for different processing speeds.
This Highly Efficient Bar Straightening Machine Is Widely Applied In
- Construction Sites: For rapid on-site rebar straightening and cutting, meeting the demands of various concrete structure constructions.
- Precast Factories: Providing precisely processed rebar for precast concrete components, improving production efficiency and product quality.
- Rebar Processing Plants: Serving as professional rebar processing equipment, enhancing the factory’s overall production capacity and automation level.
- Bridge Construction: Offering efficient and precise rebar processing for bridge structures, ensuring project quality and progress.
- Tunnel Engineering: Adapting to the complex and varied rebar processing requirements in tunnel construction, improving construction efficiency.
- Various Industrial Fields Requiring Precise Rebar Straightening and Cutting: Whether for large-scale construction projects or small-batch custom processing, the YG rebar straightening machine provides reliable and efficient solutions.
Rebar Straightening Machine Manufacturer – YG Machinery
With 15+ years of experience and CE/UL certifications, YG serves 500+ projects in 30+ countries. If you need a machine that straightens rebars while cutting them to precise lengths, our rebar straightening machine is your ultimate solution. Additionally, we also offer rebar cutting machines, rebar threading machines, rebar bending machines, rebar stirrup bending machines, stirrup bending machines, chain link fence machines, and beam bending machines. Welcome to contact us to learn more about our products. Our professional sales team will be dedicated to serving you and providing the most suitable solutions.
