The mobile shot blaster is a powerful surface treatment machine that is widely used in cleaning and roughening concrete, asphalt, and steel surfaces. It effectively removes surface impurities, cleans old coatings, and improves surface roughness and friction coefficients, making it an ideal tool for municipal projects, airport runways, and road construction.
Specifications of Mobile Shot Blaster
| Model | YG-270(Single) | YG550/600(Double) | YG-850(Double) | |
| Shot Blasting Wheel Diameter | 200mm | |||
| Working width | 270 mm | 550/600 mm | 800 mm | |
| Walking speed | 0.5~20 m/min | 0.5~33 m/min | ||
| Concrete surface cleaning efficiency | ≥180 m2/h | ≥400 m2/h | ≥600 m2/h | |
| Steel plate surface cleaning efficiency | 15-25 m2/h | 75-100 m2/h | 100-160 m2/h | |
| Dust connection pipe diameter | 120 mm | 150 mm | ||
| Suggest the diameter of steel balls | 1.2-1.5 mm | 1.5-1.8 mm | ||
| Steel pill consumption | 10 g/m2 | |||
| Supporting dust collector | Seven-core automatic backflush vacuum cleaner | Eight-core automatic backflush vacuum cleaner | ||
| Shot wheel motor | Power consumption | 11 kW | 11*2 kW | 15*2 kW |
| Input Current | ≤ 15 A | ≤ 22*2 A | ≤ 28*2 A | |
| Walking motor | Power consumption | 0.5 kW | 1.5 kW | |
| Input Current | 1 A | 3 A | ||
| Size (mm) | 1000*300*1100 | 1950*720/775*1400 | 1950*1020*1550 | |
| Weight | 150 kg | 570 kg | 700kg | |
| Power connection requirements | 400V, 50Hz, 100A, CEE socket | |||
Main Applications of the Mobile Shot Blaster
Concrete Surface Treatment
- Removal of Laitance and Impurities: Effectively removes laitance, dust, oil stains, and other impurities from concrete surfaces, providing a clean, solid base for subsequent coatings or waterproof layers.
- Cleaning Markings and Old Coatings: Efficiently cleans old markings and coatings on municipal roads and paved surfaces, restoring the road’s original appearance and improving road roughness and friction coefficients, enhancing driving safety.
- Airport Runway Cleaning: Specifically used for cleaning glue and lines from airport concrete runways, restoring and increasing the surface roughness of airport runways, significantly improving the runway’s friction coefficient, and ensuring safe aircraft takeoffs and landings. Our mobile shot blaster is an indispensable tool for airport maintenance.
Asphalt Pavement Applications
- Improving Anti-Skid Performance: Cleans attachments from asphalt surfaces, effectively improving the road’s anti-skid performance and reducing the occurrence of slippery road accidents.
- Surface Roughening Treatment: By roughening the asphalt surface, it improves the roughness and friction coefficient of asphalt pavements, enhancing road adhesion, thereby ensuring driving safety.
- Airport Runway Cleaning and Maintenance: In the cleaning and routine maintenance of airport asphalt runways, the mobile shot blaster also plays an important role, ensuring the runway remains in optimal condition.
Steel Surface Cleaning
This equipment is also ideal for cleaning steel surfaces, effectively removing rust, dirt, and other contaminants to provide a clean surface for subsequent coatings.
Advantages of the Mobile Shot Blaster
- Simple Operation, Flexible Deployment: Simple to operate and prepare. You can use and withdraw the floor shot blaster at any time, greatly improving construction flexibility and efficiency.
- Advanced Electrical Control Technology: Employs multiple advanced electrical control technologies, such as variable frequency speed control, PLC control, phase sequence protection, text display, etc., ensuring accurate realization of all functions, making the operation of the mobile shot blaster more stable and reliable.
- Precise Parameter Control: With the YG road shot blaster, you can set parameters such as cleaning speed, steel shot supply, pulse back-blowing cycle time, and dust filter cartridge cleaning interval based on different road conditions, achieving ideal cleaning results through parameter combination adjustments.
- Wide Working Range, High Efficiency: The YG concrete shot blaster has a wide working range and high efficiency, effectively shortening construction periods and saving valuable time for your projects.
- Continuous Operation Capability: Pulse automatic back-blowing and dust removal enable continuous operation, reducing downtime and improving work efficiency.
- Low Consumable Costs: Steel shot is automatically recycled within the equipment, with extremely low consumption, significantly reducing operating costs.
- Convenient Maintenance: The YG concrete shot blaster has a reasonable structure, quick disassembly, and convenient replacement of wear parts, reducing maintenance difficulty.
- Minimal Road Damage: The road structure is basically undamaged during construction, protecting the integrity of the original road surface.
- Environmentally Friendly and Pollution-Free: The entire construction process is dust-free and pollution-free, beneficial to the health of construction personnel and environmental protection, complying with modern construction’s green standards. Our mobile shot blaster is a model of environmentally friendly construction.
Application Scenarios and Scope
- Decontamination of nuclear power buildings
- Steel surface cleaning
- Overpass coating cleaning
- Airport planning and rerouting projects
- Railway bridge deck waterproofing construction
- Road bridge and tunnel surface roughening
Working Principle of the Mobile Shot Blaster
The working principle of the YG road mobile shot blaster is efficient and environmentally friendly. It mechanically projects shot material at a high speed and a certain angle onto the working surface. The shot impacts the working surface, roughening the road surface and removing residues. Subsequently, within the machine, the shot material and collected impurities are separated and recovered through the air cleaning action of a matching dust collector, allowing the shot to be reused, achieving resource circulation. The machine is equipped with an advanced dust collector, ensuring a dust-free and pollution-free construction process, both improving work efficiency and effectively protecting the environment.
Shot Blasting Machine for Sale in YG Machinery Manufacturer
YG Machinery Co., Ltd. is a manufacturer of shot blasting equipment, sandblasting machines, and environmental dust removal equipment, integrating scientific research, development, production, sales, installation, and commissioning services. We focus on providing high-quality industrial solutions, with our main products including shot blasting machinery, sand processing equipment, environmental dust removal equipment, and various mechanical accessories. Our product line is rich and diverse, including: shot blasting machines, shot blasting cabinets, sandblasting rooms, sandblasting equipment, sandblasting boxes, sandblasting pots, etc. No matter what type of shot blaster for sale you need, we can provide professional solutions.
If you are looking for a mobile shot blaster with excellent performance and a reasonable shot blasting machine price, or want to learn about detailed shot blasting machine price information, please contact us immediately.
