In the vast deserts of Nevada, mining exploration is a vital industry. A seasoned geological expert, Mr. Jackson, faced a significant challenge. He needed a high-performance reverse circulation drilling rig. It had to work efficiently in complex geological conditions. His previous rig was slow and broke down often. This cost him a lot of time and money. Mr. Jackson urgently needed a reliable solution. He started his search online and ultimately found us.
Reverse Circulation Drilling Rig Parameter
Model | YG150RC | |
Drill rig weight(crawler mounted) | kg | 9000 |
Engine Power | kW | 125 |
Length × Width × Height (normal) | mm | 6750x2200x2950 |
Ambient Temperature Range | °C | -10~38 |
Drill Ability | ||
Nominal Drill Depth | m | 150 |
End-hole Diameter | mm | 110-250 |
Drill angle | ° | -10-90 |
Horizontal hole height | m | 1.85-2.8 |
Drill head output | ||
Max Output Torque | N.m | 8000 |
Output Rotation Speed(continuity) | rpm | 30 / 60, 54/108rpm |
Output Rotation Speed(interval) | rpm | 62 / 124105/210rpm |
Feeding | mm | 3500 |
Thrust Force | kN | 45 |
Lifting Capacity | kN | 65 |
Pipe-puller Device Output | ||
Output Rotation Speed | rpm | 40 |
Max Output Torque | N.m | 30000 |
Hole-through Diameter | mm | 370 |
Auxiliary Winch | ||
Pull Force of the First Layer | kN | 11 |
Rope Diameter | mm | 14 |
Rope Capacity | m | 60 |
Engine(Cummins) | 6BTA5.9-C125 | |
Power | kW | 125 |
Rotary Speed (Max.) | rpm | 2200 |
Track Chassis Base | ||
Walk Speed | Km/h | 1.2 |
Unit Pressure | MPa | <0.05 |
Climb Ability | ° | ≥20 |
How Our RC Drill Rig Solved the Client’s Problem
Mr. Jackson’s pain point was clear. His team needed to get accurate rock samples fast. This is key for gold exploration. He heard about YG Machinery. He found us through a friend’s recommendation. Our technical team learned about his project. We knew he needed a reverse circulation drilling rig that could handle desert heat and hard rock. Our reverse drilling machine met these needs perfectly. Our equipment has a powerful hydraulic system. It ensures stable and efficient drilling.
What Makes Our Reverse Circulation Drilling Rig Stand Out?
Why did the client choose us in the end? Because we offered more than just a product. We provided a complete solution. Our reverse circulation drilling rig has several unique advantages. It uses an advanced dust collection system. This collects all drill cuttings. It protects the environment. It also ensures sample quality. Our equipment has a special cooling system. It guarantees continuous operation in high temperatures. Our service also impressed him. We gave him comprehensive pre-sales advice. We tailored a drilling plan just for him.

How the Client Used Our RC Drilling Rig
Mr. Jackson’s team worked at a new mining site in Nevada, USA. Their job was large-scale exploration drilling. They used our reverse drilling machine for the initial exploration. Our equipment performed outstandingly. It drilled quickly through hard basalt layers. Our cyclone separator provided dry cuttings instantly. This let his team perform geological analysis fast. They saved a lot of time.
Global Success: Our RC Drill Rig for Sale is Everywhere
Our success is not limited to the USA. Our products are sold worldwide. They perform well in Australia, Canada, and South Africa. These countries are huge markets for exploration drilling. Our reverse circulation drilling rig for sale has gained global recognition. Our equipment is also used for geothermal drilling and other fields. We know clients in different countries have different needs. We offer custom services for them.
The Client’s Real Feedback on Our Reverse Circulation Drilling Rig
Mr. Jackson was very happy with our product. He told us our equipment was 40% more efficient than his old rig. The breakdown rate was also much lower. He said: “YG’s RC drilling rig is the best investment we’ve made in the US. Their service is very professional.” He specifically mentioned our remote technical support. Even in the US, they got help fast. This gave him confidence in our partnership.
Why Do Global Clients Trust Us?
Our success is not an accident. We always insist on high quality. We provide clients with reliable products. YG offer professional after-sales service. This has built our good reputation worldwide. We are not just a supplier. We are a long-term partner for our clients. YG make sure every reverse circulation drilling rig creates maximum value for our clients.
