India, as one of the world’s most populous countries, its rapidly growing economy and expanding consumer market present immense demands for the packaging industry. Particularly in sectors like bottled water, beverages, edible oils, pharmaceuticals, and cosmetics, the demand for PET plastic bottles continues to surge. This trend directly drives a significant market demand for advanced bottle blowing equipment, especially efficient stretch blow moulding machine. Indian manufacturers are actively seeking equipment that can improve production efficiency, reduce energy consumption, and provide reliable performance to meet the intensifying market competition.
Stretch Blow Moulding Machine Parameter
| Water Bottle Blowing Machine | YG-2L-2 | YG-2L-4 | YG-2L-6 | YG-2L-8 |
| Cavity | 2 | 4 | 6 | 8 |
| Theory output | 2000-2700 | 4000-5000 | 6000-7200 | 8500-9000 |
| Max. volume | 2L | 2L | 2L | 2L |
| Bottle mouth maximum overall diameter | 80mm | 28-38mm | 28-38mm | 28-38mm |
| Bottle biggest diameter | 100mm | 100mm | 100mm | 100mm |
| Bottle maximum height | 330mm | 330mm | 330mm | 330mm |
| Light tube quantity | 16pcs | 40pcs | 64pcs | 32pcs |
| Light tube power | 1.5KW | 1.5KW | 1.5KW | 1.5KW |
| Maximum heating power | 24KW | 40KW | 80KW | 80KW |
| All-electric machine installation | 26KW | 60KW | 85KW | 85KW |
| Actual consumption | 19KW | 30KW | 40KW | 40KW |
| Work pressure | 7-9kg/c㎡ | 7-9kg/c㎡ | 7-9kg/c㎡ | 7-9kg/c㎡ |
| Low-pressure gas consumption | 1000L/min | 1600L/min | 1600L/min | 1600L/min |
| Blow bottle pressure | 25-35kg/c㎡ | 25-35kg/c㎡ | 25-35kg/c㎡ | 25-35kg/c㎡ |
| Higher-pressure gas consumption | 1500Ltr/min | 3000Ltr/min | 4000Ltr/min | 4800Ltr/min |
| Work pressure | 5-6 kg/c㎡ | 5-6 kg/c㎡ | 5-6 kg/c㎡ | 5-6 kg/c㎡ |
| Temperature range | 10℃ | 10℃ | 10℃ | 10℃ |
| Consumption | 5000kcal/hr | 8000kcal/hr | 8000kcal/hr | 12000kcal/hr |
| Frozen water flow | 30L/min | 88L/min | 88L/min | 88L/min |
| Size of the machine | 2.5*1.6*1.7 m | 4.5*2.0*2.3 m | 6.5*2.0*1.9 m | 6.7×2.0×2.3m |
| Weight of the machine | 2.0ton | 4.0ton | 5.5ton | 6.0ton |
YG’s Stretch Blow Moulding Machine: Meeting Diverse Production Needs
YG’s stretch blow moulding machine perfectly aligns with the diverse demands of the Indian market due to its outstanding performance and flexibility. Our machines can produce preforms of various specifications and shapes, ranging from small beverage bottles to large edible oil containers, and even specialised three-gallon and five-gallon water bottles. These machines feature a fully automatic human-machine interface, ensuring intuitive and easy operation, while maintaining stable overall machine operation, low failure rates, and rapid blowing speeds. For Indian clients looking to optimise their production processes, choosing YG’s stretch blow moulding machine means gaining a reliable production partner.
The Indian Client’s Story: Mr. Amit Chooses YG’s Stretch Blow Moulding Machine
Our Indian client, Mr. Amit, is the head of a rapidly growing plastic product manufacturing company in his region. The demand for bottled water and soft drinks in his area is very strong, and to expand capacity and improve product quality, Mr. Amit decided to invest in new bottle blowing equipment. After thoroughly researching several suppliers, Mr. Amit ultimately chose YG’s stretch blow moulding machine. He particularly valued the stability and high level of automation of YG’s equipment, which was crucial for ensuring uninterrupted operation of his production line.
Client’s Purchase Background and Satisfaction
Mr. Amit’s project background was driven by the increasing market demand for bottled drinking water. He needed a machine capable of stably and efficiently producing a large volume of PET water bottles. After evaluating various blowing machine for plastic bottle options, he was particularly attracted to YG’s stretch blow moulding machine, especially its claimed low scrap rate and energy-saving features. The usage feedback confirmed that YG’s equipment completely exceeded Mr. Amit’s expectations. He reported that the machine runs very stably, produces high-quality bottles, and indeed keeps the scrap rate at an extremely low level, significantly reducing production costs. He expressed high satisfaction with YG’s PET stretch blow moulding machine.
Leading Technical Advantages and Working Principle
YG’s stretch blow moulding machine boasts several technical advantages. Its simple structural design integrates the oven with the main sliding rail, making maintenance easy. The clever air circuit design separates action air from blowing air to meet different pressure requirements, ensuring precise blowing movements.
Stretch Blow Moulding Machine Manufacturer – YG Machinery
YG doesn’t just offer a range of plastic bottle blow molding machines; we also have a variety of supporting equipment to meet your needs. This includes blow molding molds, preform molds, and bottle cap molds. Plus, our team at YG can customize plastic molds tailored to your specific production requirements. By selecting the right blow molding machine and fine-tuning your processes, equipment, and management, you can boost production efficiency, cut costs, satisfy market demands, and increase your product sales. If you’re interested in learning more about PET blow molding machines and molds, we also provide water bottle filling machines, bottle labeling machines, and more. We have a complete production line ready for you, so feel free to reach out for a customized solution!
